SM9541-010C-D-C-3-S

描述：
       The SM9541 Series is a digital, low pressure MEMS sensor family offering state-of-the-art pressure transducer technology and CMOS mixed signal processing technology to produce a digital, fully conditioned, multi-order pressure and temperature compensated sensor in JEDEC standard SOIC-16 with a dual vertical porting option. It is available in both compound gauge or differential pressure configurations. With the dual porting, a vacuum-gauge measurement is possible to minimize altitude errors due to changes in ambient pressure.

       Combining the pressure sensor with a signal-conditioning ASIC in a single package simplifies the use of advanced silicon micro-machined pressure sensors. The pressure sensor can be mounted directly on a standard printed circuit board and a high level, calibrated pressure signal can be acquired from the digital interface. This eliminates the need for additional circuitry, such as a compensation network or microcontroller containing a customer correction algorithm.

       The SM9541 is shipped in sticks or tape & reel.

特点：
?   Fully digital,pressure calibrated and temperature compensated output
?   I2C Digital interface
?   Compensated temperature range: -5 to 65℃
?   Compound gage and differential pressure configurations
?   Insensitive to mounting orientation
?   Robust JEDEC SOIC-16 package for automated assembly
?   Manufactured according to *** and ***/TS 16949 standards
?   RoHS & REACH compliant
?   Pressure ranges from 10cm*H2O to 100cm*H2O (0.14 to 1.4 PSI)

应用：
?   Medical：Sleep Apnea；CPAP；Ventilators；Oxygenators；Negative Pressure Wound Therapy；Air Flow Monitors；Gas Flow Instrumentation
?   Industrial：Airflow Measurement；Pneumatic Gages；Pressure Switches；Safety Cabinets；Life Sciences；Gas Flow Instrumentation；Liquid Level Measurement

?   Consumer：Sports Equipment；Appliances

SM9541-010C-S-C-3-S
SM9541-010C-D-C-3-S
SM9541-020C-S-C-3-S
SM9541-020C-D-C-3-S
SM9541-040C-S-C-3-S
SM9541-040C-D-C-3-S
SM9541-100C-S-C-3-S
SM9541-100C-D-C-3-S
